| Brand Name: | Winsmart |
| Model Number: | PM0409 |
| MOQ: | 1대 pc |
| 가격: | USD1-100/Set |
| Packaging Details: | 합판 상자 |
| Payment Terms: | L/C (신용장), 전신환, 웨스턴 유니온 |
Plastic Top Bottom SMT Antistatic ESD Plastic PCB Magazine Rack 355*320*563mm
ESD PCB Magainze Rack Dimensions Introduction:
1. Dimension: 355x320x563mm, storing 50pcs of 350x(50-250)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
2. Dimension: 355x315x580mm, storing 50pcs of 350x(80-250)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
3. Dimension: 460x400x563mm, storing 50pcs of 460x(100-330)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
4. Dimension: 535x460x570mm, storing 50pcs of 535x(50-390)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
5. Dimension: 535x530x570mm, storing 50pcs of 535x(50-460)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
ESD PCB Magazine Rack Specification:
| Name | ESD PCB Magazine Rack |
| Surface resistance | 104~106 Ω |
| Overall size | 355x320x563mm |
| Storage capacity | 50pcs |
| PCB Spec | L355xW(50-250)mm |
| Side guide slot | depth 3.5mm, width 5mm, pitch 10mm |
| Heat resistant | 80°C/120°C/200 °C |
| Ref. Position | A=34mm, B=34mm |
| Materials | Aluminum + steel |
ESD PCB Magazine Rack Details:
ESD PCB Magazine Rack Package:
|
|
| Brand Name: | Winsmart |
| Model Number: | PM0409 |
| MOQ: | 1대 pc |
| 가격: | USD1-100/Set |
| Packaging Details: | 합판 상자 |
| Payment Terms: | L/C (신용장), 전신환, 웨스턴 유니온 |
Plastic Top Bottom SMT Antistatic ESD Plastic PCB Magazine Rack 355*320*563mm
ESD PCB Magainze Rack Dimensions Introduction:
1. Dimension: 355x320x563mm, storing 50pcs of 350x(50-250)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
2. Dimension: 355x315x580mm, storing 50pcs of 350x(80-250)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
3. Dimension: 460x400x563mm, storing 50pcs of 460x(100-330)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
4. Dimension: 535x460x570mm, storing 50pcs of 535x(50-390)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
5. Dimension: 535x530x570mm, storing 50pcs of 535x(50-460)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
ESD PCB Magazine Rack Specification:
| Name | ESD PCB Magazine Rack |
| Surface resistance | 104~106 Ω |
| Overall size | 355x320x563mm |
| Storage capacity | 50pcs |
| PCB Spec | L355xW(50-250)mm |
| Side guide slot | depth 3.5mm, width 5mm, pitch 10mm |
| Heat resistant | 80°C/120°C/200 °C |
| Ref. Position | A=34mm, B=34mm |
| Materials | Aluminum + steel |
ESD PCB Magazine Rack Details:
ESD PCB Magazine Rack Package:
