제품 상세 정보:
|
PCB 물자: | FR4, MCPCB | 힘: | 110V 또는 220V |
---|---|---|---|
절단 길이: | 400mm | 커팅 스피드: | 조정할 수 있습니다 |
보증: | 1년이요 | 이름: | PCB 데파넬리즘 |
하이 라이트: | Adjustable Speed PCB Depanelization Machine,110V PCB Depanelization Machine,220V PCB Separator Machine |
Low Cost Automatic PCB Depanelization Equipment PCB Separator
V-cut PCB Depanelizer Application:
1. Cutting Materials: Aluminum Board, PCB Board, Soft Fiber, clean and burr-free, high speed and effective.
2. Customer mainly from Electronics Assembly Industry like LED industry, SMT industry, Moblie/Mp3 industry, Electronic Toys industry and Etc...
3. Imported high speed steel blade, long service life. Easy operating, processing without board stress, will not demage the components on the board.
V-cut PCB Depanelizer Specs:
Model | SMTAD5 |
Machine Dimension | L740*W550*H460 |
Max Cutting Length | 400mm |
PCB Material | FR4, MCPCB |
Cutting Speed | 300mm/s or 500mm/s |
PCB Thickness | 0.6-2.0mm |
Power | 220/110V |
Machine Weight | 60kgs |
V-cut PCB Depanelizer Features:
1. Lower cutting stress to protect PCBs.
2. Blade movement to protect components from damage.
3. Separating speed is adjusted by a rotary knob.
4. There is safe sensor to ensure safe operation
5. Full-featured, flexible LCD
6. Optional conveyor belt
7. Solve less 1.0mm "V" grooves separating
8. "V" groove guide device can adjust the vertical height to fit different thickness of PCBs
9. Blades could be re-sharpened
10. Blades could be customized as customers’ request
Warranty Period and Service Scope
The equipment has been debugged and checked before leaving the factory, and the company will guarantee its use within the following conditions.
1. Warranty period
One year after leaving the factory
2. Service scope
During the warranty period, the company will repair the fault free of charge, but the following conditions will not be covered by the warranty.
1. Use consumables and components not specified by the company.
2. Improper use or maintenance by operators.
3. Normal consumption of consumables.
4. Other natural disasters.
